步距角

0.9°

步距角精度

±5% (full step, no load)

電阻公差

±10% @20℃

電感公差

±20% @1kHz

溫升

80℃ Max.(rated current)

環(huán)境溫度

-20℃~+50℃

絕緣電阻

100MΩMin. ,500VDC

介電強(qiáng)度

500VAC for one minute

徑向間隙

0.02Max. (450 g-load)

軸向間隙

0.08Max. (450 g-load)

V

A

Ω

mH

kg. cm

g-cm2

kg

mm

57HS41M-2006A

2.8

2

1.4

2.2

3.9

6

120

0.47

41

57HS41M-2804A

2

2.8

0.7

2.2

5.5

4

120

0.47

41

57HS56M-2006A

3.6

2

1.8

4.5

9

6

300

0.7

56

57HS56M-2804A

2.5

2.8

0.9

4.5

12.6

4

300

0.7

56

57HS76M-2006A

4.5

2

2.25

5.6

13.5

6

480

1

76

57HS76M-2804A

3.2

2.8

1.13

5.6

18.9

4

480

1

76
